3 axles 4 axles 40T 60T 80T 100T 120T low boy low bed semitrailer
Name: low bed semitrailer
Trailer Model: JTM9412L
Loading Capacity: 40T 60T 80T 100T 120T
Dimension: 12000-17800mm x 2500-3000mm x 1490-1770mm
Function: carry excavator,bulldozer,bus or other vehicles
Top flange plate: Material and thickness: 16-24mm Q345B
Bottom flange plate: Material and thickness: 18-24mm Q345B
Middle flange plate: Material : Q345B
Thickness: 8-14mm
Height: 500-580mm
Side beam: 16-30mm I steel 140-240mm channel steel
Floor plate: 3mm-10mm diamound
Axle: Brand : FUWA/BPW/JINSHENG
Type: 13T-20T
Number: 3/4/5 pcs
Rim: Type: 6.5-20,7.5-20,8.0-20,8.5-20
Number: 12/16/20 pcs
Tire: Brand : Triangle / Double coin/ Goodyear
Type: 8.25R20,10.00R20,11.00R20,12.00R20
Number: 12/16/20 pcs
Suspension: Mechaniacal suspension or Air suspension
Spring Leaf: Leaf width: 90mm/100mm/120mm
Leaf thickness: 16/13/11mm
layer/set: 10/15/17 layers
Kin pin: Type: Bolt or welded JOST Brand
Diameter: 2 inch(50#) or 3.5 inch(90#)
Brake system: RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
Relay valve: WABCO/ KORMEE
Gas tank: 2 or 3 pcs aluminum
Landing gear: Brand : 28T JOST or SHUTSU (19")
type: single speed/double speed
Lamp: Manually operated or Hydraulic type
Wheelbase: 1310 mm
Spare tire carrier: 1 set or 2 sets
Light: LED light
Voltage: 24V
Receptacle: 7 ways (7 wire harness)
Tool box: according to drawing
Painting: Polyurethane paint&anti-rust primer&sand blasting
Side guard: According to customer's requirement
Packing: Polish with wax before shipping
Delivery way: RO-RO, Bulk cargo , 40HQ container
